Description

Built for sites handling consistent pallet loads, this Sitecraft Powder Coated Spring Pallet Positioner keeps work at the right height without constant adjustment. It suits warehouses, packing lines, and manufacturing environments where reducing bending and repetitive strain is a priority.

This model is a forklift-compatible solution for operations that don’t require frequent relocation but demand reliable, high-capacity performance. With a 2000kg capacity and heavy-duty powder coated steel construction, it’s designed to handle ongoing industrial use without compromise.

The spring-loaded platform automatically raises and lowers as weight changes, keeping the top layer of the pallet at an ergonomic working height. Combined with a rotating top, operators can access all sides from one position — reducing unnecessary movement and improving consistency across shifts.

Adjustable spring configurations allow you to match the unit to different load weights, ensuring stable and predictable performance across varying applications. A protective cover reduces pinch point risk, supporting safer day-to-day operation.

This is a practical choice where workflow consistency, manual handling reduction, and long-term reliability matter more than mobility.

Key Specifications & Configuration

  • Load Capacity: 2000kg
  • Platform Diameter: 1100mm
  • Height: 700mm
  • Unit Weight: 170kg
  • Finish: Powder coated steel
  • Spring System: 3 springs (4 load configurations)
  • Function: Self-levelling + rotating top
  • Compatibility: Forklift handling
  • Safety: Protective cover to reduce pinch point
  Primary Applications
  • Pallet packing and unpacking stations
  • Assembly and production lines
  • Warehousing and distribution centres
  • Repetitive order picking or kitting tasks
  • Environments focused on reducing manual handling strain

Product video

Sitecraft Spring Pallet Positioner | Powder Coated | 2000kg

-
+
1 Year Warranty
Trusted specialist advice
Built with durability in mind
Specifications
Product Code 5781417
Product Name Sitecraft Spring Pallet Positioner | Powder Coated | 2000kg
Diameter (mm) 1100mm
Height (mm) 700mm
Load Capacity (kg) 2000kg
Net Weight (kg) 170

We offer delivery across Australia, with freight costs based on your order and delivery requirements.

For shipments over 20 kg, freight costs are subject to a forklift or stacker being available onsite for unloading.

*Additional charges may apply if tailgate unloading is required.

Please contact us before ordering if you require this service.

Returns are subject to our applicable terms and conditions. For full details on delivery requirements, freight and returns, please view our Delivery & Returns Policy.
