Heavy Duty 20 Pallet Squarer

Code: 13441419

20-Pallet Solution — High-Capacity Storage for Heavy-Duty Operations

Best for: Large warehouses, distribution centres, manufacturing plants, and operations managing high-volume palletised goods.

The 20-pallet configuration is engineered for businesses that need maximum pallet density and heavy-duty performance. It allows teams to consolidate bulk stock, minimise handling time, and maintain smooth throughput in demanding environments.
With its high storage volume, this format supports large procurement cycles, bulk receiving, and centralised inventory control — making it ideal for operations where uptime, efficiency, and productivity are non-negotiable.

High-capacity 20-pallet design for large warehouses, DCs and high-turnover operations
Super heavy-duty Australian-made construction built for long-term industrial use
Full-size tapered wings guide misaligned stacks smoothly into position
Large structural frame: 3000mm (H) × 1950mm (W) × 1550mm (D)
Tapered opening down to 1200 × 1200mm for consistent pallet alignment
2 × rear bracing legs add load stability during stacking
16mm base plate with bolt-down capability for secure installation
Supplied with fixings: 12 × M20 anchors + 8 × M16 anchors
2 × carrying lugs for easy onsite manoeuvring
Ideal for heavier forklift traffic and continuous pallet stacking

Specifications

Product Code 13441419
Product Name Heavy Duty Pallet Squarer – 20 Pallet
Depth (mm) 1550mm
Height (mm) 3000mm
Width (mm) 1950mm

Specifications

Product Code 13441419
Product Name Heavy Duty Pallet Squarer – 20 Pallet
Depth (mm) 1550mm
Height (mm) 3000mm
Width (mm) 1950mm
