Built on our popular MP-250 base, the more powerful MT-290 is equal parts modern workhorse and mobile workshop. Its efficient AC motor offers impressive acceleration, even when towing loads of 7,250 kg.* Its all-steel construction and four-wheel vibration-dampening design ensure a smooth and stable ride even on bumpy surfaces. This agile, round-the-clock tow tractor effortlessly maneuvers through challenging areas, including doorways. A multi-purpose tow tractor boasting a long-lasting industrial battery with easy under-the-seat access. EE rating available.
PASSENGER | LOAD CAPACITY | TOWING CAPACITY | SPEED | TURNING RADIUS |
|---|
Specifications and standard equipment are subject to change without notice. | |||||
|---|---|---|---|---|---|
36V HD | 1 | 320 kg | 4535 kg | 13 kmh | 1960 mm |
48V | 1 | 320 kg | 4535 kg | 13 kmh | 1960 mm |
48V Lithium | 1 | 320 kg | 7260 kg | 13 kmh | 1960 mm |
36V HD | |
|---|---|
Passengers | 1 |
Load Capacity | 320 kg |
Towing Capacity | 4535 kg |
Speed | 13 kmh |
Turning Radius | 1960 mm |
48V | |
|---|---|
Passengers | 1 |
Load Capacity | 320 kg |
Towing Capacity | 7260 kg |
Speed | 13 kmh |
Turning Radius | 1960 mm |
48V Lithium | |
|---|---|
Passengers | 1 |
Load Capacity | 320 kg |
Towing Capacity | 7260 kg |
Speed | 13 kmh |
Turning Radius | 1960 mm |
36V HD | 48V | 48V Lithium |
|---|---|---|
POWER TRAIN | |||||
|---|---|---|---|---|---|
Motor | |||||
Brushless AC motor, 7.5 HP Intermittent, 10 HP Max | Brushless AC motor, 9 HP Intermittent, 15 HP Max | 15 HP Brushless AC motor | |||
Drive Axel | |||||
Helical gear differential | Helical gear differential | Helical gear differential | |||
Transmission | |||||
Direct drive | Direct drive | Direct drive | |||
Controller | |||||
Electronic AC speed controller | Electronic AC speed controller | Electronic AC speed controller | |||
ENERGY | ||
|---|---|---|
Voltage | ||
36V | 48V | 48V |
Battery | ||
No battery included | No battery included | Lithium 48V-180Ah 9.3Kwh, Lithium 48V-240 Ah 12.4Kwh |
Charger | ||
No charger included | No charger included | 48V High-frequency on-board charger 1.2Kwh, 48V High-frequency on-board charger 2.4Kwh |
CHASSIS | ||
|---|---|---|
Body | ||
All-steel unibody construction | All-steel unibody construction | All-steel unibody construction |
Suspension | ||
Dual leaf springs on rear | Dual leaf springs on rear | Dual leaf springs on rear |
Brakes | ||
Rear hydraulic drum brakes, regenerative braking | Rear hydraulic drum brakes, Rear dual drum brakes | Rear hydraulic drum brakes, Rear dual drum brakes |
Wheels | ||
4.8×8 LRC pneumatic tyres | 4.8×8 LRC pneumatic tyre | 4.8×8 LRC pneumatic tyre |
Steering | ||
Automotive steering wheel | Automotive steering whee | Automotive steering wheel |
Seats | ||
Bucket seat on slide adjusters | Bucket seat on slide adjusters | Bucket seat on slide adjusters |
EQUIPMENT | |||||
|---|---|---|---|---|---|
Lights | |||||
LED headlight & tail/brake light | LED headlight & tail/brake light | LED headlight & tail/brake light | |||
Indicators | |||||
Multifunction display (including speedometer, battery state of charge, hour meter, odometer and fault warnings), Password-protected parameters and monitoring capability | Multifunction display (including speedometer, battery state of charge, hour meter, odometer and fault warnings), Password-protected parameters and monitoring capability | Multifunction display (including speedometer, battery state of charge, hour meter, odometer and fault warnings), Password-protected parameters and monitoring capability | |||
Accessories | |||||
– | – | – | |||
Safety | |||||
– | – | – | |||
Specifications and standard equipment are subject to change without notice.
Motor | |
|---|---|
36V HD | Brushless AC motor, 7.5 HP Intermittent, 10 HP Max |
48V | Brushless AC motor, 9 HP Intermittent, 15 HP Max |
48V Lithium | 15 HP Brushless AC motor |
Drive Axle | |
|---|---|
36V HD | Helical gear differential |
48V | Helical gear differential |
48V Lithium | Helical gear differential |
Transmission | |
|---|---|
36V HD | Direct drive |
48V | Direct drive |
48V Lithium | Direct drive |
Controller | |
|---|---|
36V HD | Electronic AC speed controller |
48V | Electronic AC speed controller |
48V Lithium | Electronic AC speed controller |
Voltage | |
|---|---|
36V HD | 36V |
48V | 48V |
48V Lithium | 48V |
Battery | |
|---|---|
36V HD | No battery included |
48V | No battery included |
48V Lithium | Lithium 48V-180Ah 9.3Kwh, Lithium 48V-240 Ah 12.4Kwh |
Charger | |
|---|---|
36V HD | No charger included |
48V | No charger included |
48V Lithium | 48V High-frequency on-board charger 1.2Kwh, 48V High-frequency on-board charger 2.4Kwh |
Body | |
|---|---|
36V HD | All-steel unibody construction |
48V | All-steel unibody construction |
48V Lithium | All-steel unibody construction |
Suspension | |
|---|---|
36V HD | Dual leaf springs on rear |
48V | Dual leaf springs on rear |
48V Lithium | Dual leaf springs on rear |
Brakes | |
|---|---|
36V HD | Rear hydraulic drum brakes, regenerative braking |
48V | Rear hydraulic drum brakes, Rear dual drum brakes |
48V Lithium | Rear hydraulic drum brakes, Rear dual drum brakes |
Wheels | |
|---|---|
36V HD | 4.8×8 LRC pneumatic tyres |
48V | 4.8×8 LRC pneumatic tyre |
48V Lithium | 4.8×8 LRC pneumatic tyre |
Steering | |
|---|---|
36V HD | Automotive steering wheel |
48V | Automotive steering whee |
48V Lithium | Automotive steering wheel |
Seats | |
|---|---|
36V HD | Bucket seat on slide adjusters |
48V | Bucket seat on slide adjusters |
48V Lithium | Bucket seat on slide adjusters |
Lights | |
|---|---|
36V HD | LED headlight & tail/brake light |
48V | LED headlight & tail/brake light |
48V Lithium | LED headlight & tail/brake light |
Indicators | |
|---|---|
36V HD | Multifunction display (including speedometer, battery state of charge, hour meter, odometer and fault warnings), Password-protected parameters and monitoring capability |
48V | Multifunction display (including speedometer, battery state of charge, hour meter, odometer and fault warnings), Password-protected parameters and monitoring capability |
48V Lithium | Multifunction display (including speedometer, battery state of charge, hour meter, odometer and fault warnings), Password-protected parameters and monitoring capability |
Accessories | |
|---|---|
36V HD | – |
48V | – |
48V Lithium | – |
Safety | |
|---|---|
36V HD | – |
48V | – |
48V Lithium | – |
Specifications and standard equipment are subject to change without notice.
