Motrec MT-340 Tow Tractor

Motrec MT-340 Tow Tractor

VEHICLE TYPE | Utility Electric Vehicles
Code: 64491035_M

The industry benchmark for compact tow tractors has once again raised the bar. Still a quiet and low-maintenance workhorse with an unbeatable turning radius and up to 9,000 Kg. towing capacity, but now with leaf spring suspension and shock absorbers, flat-free solid softy tyres, inching control, protected electrical components and much more – all standard. Power and performance are delivered through a brushless AC powertrain with efficient direct-drive differential, hefty 25mm rear-end plate and large drum brakes. We’ve also got your back with a long list of standard ergonomic and safety features. EE rating avaialble.

PASSENGER
LOAD CAPACITY
TOWING CAPACITY
SPEED
TURNING RADIUS
Specifications and standard equipment are subject to change without notice.
36V
1
230 kg
7250 kg
13 kmh
1490 mm
48V
1
230 kg
7250 kg
13 kmh
1490 mm
48V HD
1
230 kg
9070 kg
13 kmh
1720 mm
36V
Passengers
1
Load Capacity
230 kg
Towing Capacity
7250 kg
Speed
13 kmh
Turning Radius
1490 mm
48V
Passengers
1
Load Capacity
230 kg
Towing Capacity
7250 kg
Speed
13 kmh
Turning Radius
1490 mm
48V HD
Passengers
1
Load Capacity
230 kg
Towing Capacity
9070 kg
Speed
13 kmh
Turning Radius
1720 mm
MT-340_Top
MT-340_Side
MT-340_Turn
36V
48V
48V HD
POWER TRAIN
Motor
10 HP brushless AC motor
15 HP brushless AC motor
15 HP brushless AC motor
Drive Axel
Helical gear differential
Helical gear differential
Helical gear differential
Transmission
Direct drive
Direct drive
Direct drive
Controller
Electronic AC speed controller
Electronic AC speed controller
Electronic AC speed controller
ENERGY
Voltage
36V
48V
48V
Battery
Battery to be specified
Battery to be specified
Battery to be specified
Charger
Charger to be specified
Charger to be specified
Charger to be specified
CHASSIS
Body
All-steel unibody construction, 25mm rear-end plate, powder coating
All-steel unibody construction, 25mm rear-end plate, powder coating
All-steel unibody construction, 25mm rear-end plate, powder coating
Suspension
Leaf springs rear suspension system
Leaf springs rear suspension system
Leaf springs rear suspension system
Brakes
Rear wheel hydraulic drum brakes, regenerative braking
Rear wheel hydraulic drum brakes, regenerative braking
Rear wheel hydraulic drum brakes, regenerative braking
Wheels
Solid Tyres
Solid Tyres
Solid Tyres
Steering
Automotive steering wheel
Automotive steering wheel
Automotive steering wheel
Seats
Semi-suspension seat on slide adjusters
Semi-suspension seat on slide adjusters
Semi-suspension seat on slide adjusters
EQUIPMENT
Lights
LED dual headlights & tail/brake lights
LED dual headlights & tail/brake lights
LED dual headlights & tail/brake lights
Indicators
Multifunction display including speedometer, battery state of charge, hour meter, odometer and fault warnings. Password-protected parameters and monitoring capability.
Multifunction display including speedometer, battery state of charge, hour meter, odometer and fault warnings. Password-protected parameters and monitoring capability
Multifunction display including speedometer, battery state of charge, hour meter, odometer and fault warnings. Password-protected parameters and monitoring capability
Accessories
36V/12V converter for 12-volt accessories, backlit and sealed buttons
48V/12V converter for 12-volt accessories, backlit and sealed buttons
48V/12V converter for 12-volt accessories, backlit and sealed buttons
Safety
Reverse alarm, deadman seat switch, horn, emergency stop button, anti slip griptape
Reverse alarm, deadman seat switch, horn, emergency stop button, anti slip griptape
Reverse alarm, deadman seat switch, horn, emergency stop button, anti slip griptape

Specifications and standard equipment are subject to change without notice.

Motor
36V
10 HP brushless AC motor
48V
15 HP brushless AC motor
48V HD
15 HP brushless AC motor
Drive Axle
36V
Helical gear differential
48V
Helical gear differential
48V HD
Helical gear differential
Transmission
36V
Direct drive
48V
Direct drive
48V HD
Direct drive
Controller
36V
Electronic AC speed controller
48V
Electronic AC speed controller
48V HD
Electronic AC speed controller
Voltage
36V
36V
48V
48V
48V HD
48V
Battery
36V
Battery to be specified
48V
Battery to be specified
48V HD
Battery to be specified
Charger
36V
Charger to be specified
48V
Charger to be specified
48V HD
Charger to be specified
Body
36V
All-steel unibody construction, 25mm rear-end plate, powder coating
48V
All-steel unibody construction, 25mm rear-end plate, powder coating
48V HD
All-steel unibody construction, 25mm rear-end plate, powder coating
Suspension
36V
Leaf springs rear suspension system
48V
Leaf springs rear suspension system
48V HD
Leaf springs rear suspension system
Brakes
36V
Rear wheel hydraulic drum brakes, regenerative braking
48V
Rear wheel hydraulic drum brakes, regenerative braking
48V HD
Rear wheel hydraulic drum brakes, regenerative braking
Wheels
36V
Solid Tyres
48V
Solid Tyres
48V HD
Solid Tyres
Steering
36V
Automotive steering wheel
48V
Automotive steering wheel
48V HD
Automotive steering wheel
Seats
36V
Semi-suspension seat on slide adjusters
48V
Semi-suspension seat on slide adjusters
48V HD
Semi-suspension seat on slide adjusters
Lights
36V
LED dual headlights & tail/brake lights
48V
LED dual headlights & tail/brake lights
48V HD
LED dual headlights & tail/brake lights
Indicators
36V
Multifunction display including speedometer, battery state of charge, hour meter, odometer and fault warnings. Password-protected parameters and monitoring capability.
48V
Multifunction display including speedometer, battery state of charge, hour meter, odometer and fault warnings. Password-protected parameters and monitoring capability
48V HD
Multifunction display including speedometer, battery state of charge, hour meter, odometer and fault warnings. Password-protected parameters and monitoring capability
Accessories
36V
36V/12V converter for 12-volt accessories, backlit and sealed buttons
48V
48V/12V converter for 12-volt accessories, backlit and sealed buttons
48V HD
48V/12V converter for 12-volt accessories, backlit and sealed buttons
Safety
36V
Reverse alarm, deadman seat switch, horn, emergency stop button, anti slip griptape
48V
Reverse alarm, deadman seat switch, horn, emergency stop button, anti slip griptape
48V HD
Reverse alarm, deadman seat switch, horn, emergency stop button, anti slip griptape

Specifications and standard equipment are subject to change without notice.
