Performance
• The Innovative AC drive system offers strong power, accurate control,
and excellent performance
• High strength verticle gearbox for longer working life
• Low-noise durable hydraulic system
• Compact size for optimal maneuverability, 1707mm turning radius
• Proportional lifting system enables the operator to stack and retrieve pallets with precision.
Safety
• Hydraulic check valve prevents mast falling quickly in the event of hydraulic pressure loss.
• Emergency reverse belly button protects the operator.
• Emergency power disconnect cuts power should operator lose control of stacker.
• Multiple lifting limit protection
• Speed reduction when turning to ensure safe operation Operation
• Ergonomic tiller head
• Compact design
• Electric power steering for easy use
• Includes foldable rider platform and arm guard Maintenance
• AC Traction Motor - Maintenance free
• Hour meter and battery indicator
• Low voltage cut off protects battery
High ground clearance for comfortable travel on Uneven Surface
• High ground clearance 116mm
• Mast Height Lowered 2018mm
• Mast height Extended: 3915mm
• Battery: Lithium 24v 50AH
• Charger Included: 24V-30A External
• Service Brake Electromagnetic
• Key On/Off Switch
• Battery Meter
• AC motor
• Power Steering
| Fork Length (mm) | 1070 |
| Load Capacity (kg) | 1500 |
| Load Centre Distance (mm) | 500 |
| Max Lift Height (mm) | 3000 |
| Overall Length (mm) | 2968 |
| Weight (kg) | 2160 |
| Width (mm) | 900 |
| Fork Length (mm) | 1070 |
| Load Capacity (kg) | 1500 |
| Load Centre Distance (mm) | 500 |
| Max Lift Height (mm) | 3000 |
| Overall Length (mm) | 2968 |
| Weight (kg) | 2160 |
| Width (mm) | 900 |
